ALS50T-C
ALUZ » A1-ZUCO-CRN

Features

Applications
Accent, Cove, Under-Cabinet Lighting
Lamp Type
High, Mid, or Standard Output LEDs (No Mercury)
CRI
High Output (HO) > 95
Mid Output (MO) > 90
Standard Output (SO) > 85
Lens
Clear, 50% Semi-Frosted, or 100% Frosted
Optics & Asymmetric
15°, 30°, 45°, 60°, 120° or Asymmetric Optics
Length
Built to Order
Construction
Aluminum Extrusion
Weight
0.44 lbs per foot
Mounting
Mounting Clips (Sold Separately)
Listing
Dry or Wet (IP65 or IP67) Location
UL1598, CSA C22.2#250.0
UL8750, CSA250
UL2108, CSA C22.2 #9

Electrical

Dimming
Forward / Reverse Phase, 0-10V, Lutron, DMX, DALI
MAXIMUM RUN
(Class 2 Applications)
36’ (1.5W, 2W), (28' (3W), 21’ (4W)
17’ (5W), 14’ (6W), 10’ (8W),
10’ (8W), 7’ (12W)
Primary Voltage
120V - 277V (UNV) or 120V (Lutron LTEA Only)
Secondary Voltage
24VDC
DRIVER
Remote
Temperature Ratings
Operating / Startup: -20° to 48°C (-4° to 120°F)
Storage: -40° to 76°C (-40° to 170°F)

Series Downloads

LED Color Options

Certifications

Related Categories

, , , , ,


  • alumLEDs ALS50T-C Image #01
  • alumLEDs ALS50T-C Image #02
alumLEDs ALS50T-C Image #0101 alumLEDs ALS50T-C Image #0202

Designed for indoor or outdoor use, alumLEDs is ideal for many applications including the amusement, recreation, and architectural industries. alumLEDs is excellent for cove lighting, undercabinet lighting, accent lighting, and many more applications.

Lens

Clear Lens
Visible Diode Image
(CL)
50% Semi-Frosted Lens
Slight Diode Image
(SF)
100% Frosted Lens
No Diode Image (Line of Light)
(F)
Optic Lens
Slight Diode Image
(15D, 30D, 45D, 60D)
Asymmetric Lens
Slight Diode Image
(ASM)

Beam Angles

120° x 120° Beam
Clear Lens
Semi-Frosted Lens
Frosted Lens
(CL, SF, F)
45° x 60° Beam
Asymmetric Lens
(ASM)


15° x 60° Beam
Optic Lens
(15D)


30° x 60° Beam
Optic Lens
(30D)


45° x 60° Beam
Optic Lens
(45D)
60° x 60° Beam
Optic Lens
(60D)

Continuous Connectors
Connects two continuous runs and around corners
(Click on an Option for Soldering Instructions)

Continuous Connector
ALS50T-CC (3” Standard)
ALS50T-CC-X
(X = Specify Length)
Splice Connector
ALS50T-SC-WET

Mounting Options (Click on an Option for Additional Information)

ALS50T-C-MC-1
ALS50T-C-MC-2
ALS50T-C-MC-3
(Adjustable)
ALS50T-C-MC-4-X
X=Specify Length

Cove Design Guidelines (Click on an Option for Additional Information)

ALS50T-C-MC-1
ALS50T-C-MC-2
ALS50T-C-MC-3
(Adjustable)
ALS50T-C-MC-4-X
X=Specify Length

Continuous Connectors
Connects two continuous runs and around corners
(Click on an Option for Soldering Instructions)

Continuous Connector
ALS50T-CC (3” Standard)
ALS50T-CC-X
(X = Specify Length)
Splice Connector
ALS50T-SC-WET

Mounting Options (Click on an Option for Additional Information)

ALS50T-C-MC-1
ALS50T-C-MC-2
ALS50T-C-MC-3
(Adjustable)
ALS50T-C-MC-4-X
X=Specify Length

Lens

Clear Lens
(CL)
Semi-Frosted Lens
(SF)
Frosted Lens
(F)
Asymmetric Lens
(15D, 30D, 45D, 60D)
Optic Lens
(ASM)

Cove Design Guidelines (Click on an Option for Additional Information)

ALS50T-C-MC-1
ALS50T-C-MC-2
ALS50T-C-MC-3
(Adjustable)
ALS50T-C-MC-4-X
X=Specify Length
