LLED8000-ST

Features

Applications
Accent, Decorative, Surface, Recessed, Pendant Lighting
Lamp Type
LEDs
CRI
> 95
Viewing Angle
120°
Mounting
Mounting Channel or Mounting Clips (Sold Separately)
Weight
0.049 lbs per foot
Construction
Polycarbonate Extrusion
Length
Built to Order
Listing
Dry, Wet, or IP67 Location
UL2108, CSA C22.2 #9
UL8750, CSA250

Electrical

Dimming
Forward Phase, 0-10V, Lutron, DALI
Maximum Run
(Based on 5 Amps)
18’ (6.5W), 21’ (5.5W), 26’ (4.5W), 33’ (3.6W), 36’ (1.5W, 2.5W)
Maximum Run
(Based on 4 Amps for Class II)
14’ (6.5W), 17’ (5.5W), 21’ (4.5W),26’ (3.6W), 36’ (1.5W, 2.5W)
Voltage
24VDC
Driver
Remote (Sold Separately)
Temperature Ratings
Operating / Startup: -20° to 48°C (-4° to 120°F)
Storage: -40° to 76°C (-40° to 170°F)

Series Downloads

LED Color Options

Recent Projects

Sony Pictures

Control

Certifications

Related Categories

, , , , , , , , , , , , , ,


  • lipLEDs LLED8000-ST Image #01
  • lipLEDs LLED8000-ST Image #02
lipLEDs LLED8000-ST Image #0101 lipLEDs LLED8000-ST Image #0202

Designed for indoor or outdoor use, the lipLEDs Series is ideal for many applications including the amusement, recreation, and architectural industries. lipLEDs are excellent for decorative lighting, accent lighting, path lighting, and many more applications.

lipLEDs are used in: Restaurants, Casinos, Retail Stores, Shopping Malls, Hotels, Movie Theatres, and many more.

Lens

Clear Lens
Visible Diode Image
(CL)
50% Semi-Frosted Lens
Slight Diode Image
(SF)
100% Frosted Lens
Slight Diode Image
(F)

Connectors (Click on an Option for Additional Information)

Power Connector
Dry Location
LLED8000-PC
(33” Standard)
LLED8000-PC-X
(X = Specify Length)
Continuous Connector
LLED8000-CC
(3” Standard)
LLED8000-CC-X
(X = Specify Length)

Wet Location Connector (Click on an Option for Soldering Instructions)

Wet Splice Connector
LLED8000-SC-WET

Mounting Options (Click on an Option for Additional Information)

Mounting Clip
LLED8000-ST-MC
Mounting Clip
LLED8000-ST-UC

Connectors (Click on an Option for Additional Information)

Power Connector
Dry Location
LLED8000-PC
(33” Standard)
LLED8000-PC-X
(X = Specify Length)
Continuous Connector
LLED8000-CC
(3” Standard)
LLED8000-CC-X
(X = Specify Length)

Wet Location Connector (Click on an Option for Soldering Instructions)

Wet Splice Connector
LLED8000-SC-WET

Mounting Options (Click on an Option for Additional Information)

Mounting Clip
LLED8000-ST-MC
(1.5W, 2.5W, 3.6W,4.5W)
Mounting Clip
LLED8000-ST-MC-1
(5.5W, 6.5W)

Lens

Clear Lens
Visible Diode Image
(CL)
50% Semi-Frosted Lens
Slight Diode Image
(SF)
100% Frosted Lens
Slight Diode Image
(F)
