ALS500T-SMR

Features

Applications
Surface Mount Direct View
Lamp Type
High Output LEDs (No Mercury)
CRI
>90 (High Output)
Lens
100% Frosted
(No Pixelation: Line of Light)
Length
Built to Order:
Custom Lengths up to 8’
(No Seams)
Specify Overall Length
(Minimum: 2’, Maximum: 8’)
Example: 7’8” = One 7’8” fixture (Custom Length)
Example: 3’2” = One 3’2” fixture (Custom Length)
Example: 13’6” = 8’ + 5’6”
Example: 23’8” = 8’ + 8’ + 7’8”
Construction
Aluminum Extrusion
Weight
1.09 lbs per foot
Mounting
Mounting Plates
Listing
Dry, Damp, or Wet Location
UL1598, CSA C22.2#250.0
UL8750, CSA250
UL2108, CSA C22.2 #9

Electrical

Dimming
0-10V, DMX, DALI
Maximum Run
40’ (4W, 5W, 6W, 8W)
26’ (12W)
Primary Voltage
120V - 277V (UNV)
Driver
Integral (Driver on Board)
Temperature Ratings
Operating / Startup:
-20° to 48°C (-4° to 120°F)
Storage:
-40° to 76°C (-40° to 170°F)

Series Downloads

LED Color Options

Standard Color Finishes

Control

Certifications

Related Categories

, , , , ,


  • alumLEDs ALS500T-SMR Image #01
  • alumLEDs ALS500T-SMR Image #02
alumLEDs ALS500T-SMR Image #0101 alumLEDs ALS500T-SMR Image #0202

Designed for indoor or outdoor use, alumLEDs is ideal for many applications including the amusement, recreation, and architectural industries. alumLEDs is excellent for cove lighting, undercabinet lighting, accent lighting, and many more applications.

Lens

100% Frosted Lens
No Diode Image
(Line of Light)
(F)

End Views

Dry or Damp Location
(No Screws)
Wet Location
(Visible Screws)

Accessories

Flush Mounting Plate
ALS500T-SMR-MP
Hardwire Connector
(ALS500T-SMR-HWC)
End Cap
(Dry or Damp Location Only)
(ALS500T-SMR-EC)

Accessories

Flush Mounting Plate
ALS500T-SMR-MP
Hardwire Connector
(ALS500T-SMR-HWC)
End Cap
(Dry or Damp Location Only)
(ALS500T-SMR-EC)

Lens

100% Frosted Lens
No Diode Image
(Line of Light)
(F)
